Anti-flaming plastic optical cable is made of plastic optical fiber, which is excellent short data transmission medium,with special anti-flaming jacket material.
Simplex Anti-Flaming Pof Cable
NewDescription
Description
TXPOF 1.0*2.2mm plastic optical fiber TX-CC1000-1AV
1.0/2.2 Low attenuation PMMA Simplex anti-flaming pof cable
Anti-flaming plastic optical cable is made of plastic optical fiber, which is excellent short data transmission medium,with special anti-flaming jacket material. Plastic optical cable is immune to electromagnetic wave radiation, noise , has a good capacity of resisting distance. Plastic optical fibers have a higher bandwidth than other transmission material like copper, while it is energy-saving environment protection. Plastic optical fibers are widely used in FTTH, CPN, LAN, industrial control, military communication monitor system, consumer electronics, airborne equipment automobile intelligence so on.
Specifications
UL VW-1 level & UL OFN level
Cladding Diameter: 1000µm
Jacket Diameter:2.2 mm
Number of fiber :1
Minimum Bend Radius:25mm
Tensile strenght:70N
Transmission Loss: ≤ 180 dB/km @650nm
Numerical Aperture: 0.5NA
Core Refractive Index:1.49
Temperature Range:-55°C to +70°C
Customization: customized logo on the cable
RoHS/REACH Compliant
| Model | Core
(mm) |
OD
(mm) |
Attenuation
(dB/km) |
Jacket
Material |
Meters/roll
（meter） |
Temperature
（℃） |
| TX-CC0500-1B | 0.5mm×1 | 1.0mm±0.15 | ≤250 | PE | 1500/5000 | -55~70 |
| TX-CC0500-1B/1.25 | 0.5mm×1 | 1.25mm±0.15 | ≤250 | PE | 1500/5000 | -55~70 |
| TX-CC0750-1B | 0.75mm×1 | 2.2mm±0.07 | ≤200 | PE | 2500 | -55~70 |
| TX-CC1000-1B/1.25 | 1.0mm×1 | 1.25mm±0.15 | ≤200 | PE | 1500/5000 | -55~70 |
| TX-CC1000-1B | 1.0mm×1 | 2.2mm±0.07 | ≤200 | PE | 2500/5000 | -55~70 |
| TX-CC1000-1A | 1.0mm×1 | 2.2mm±0.07 | ≤180 | PE | 2500/5000 | -55~70 |
| TX-CC1500-1/3.0 | 1.5mm×1 | 3.0mm±0.1 | ≤240 | PE/PVC | 700 | -55~70 |
| TX-CC2000-1/3.8 | 2.0mm×1 | 3.8mm±0.1 | ≤240 | PE/PVC | 350 | -55~70 |
| TX-CC3000-1/4.5 | 3.0mm×1 | 4.5mm±0.1 | ≤240 | PE/PVC | 150 | -55~70 |
| TX-CC3000-1/5.0 | 3.0mm×1 | 5.0mm±0.1 | ≤240 | PE/PVC | 150 | -55~70 |
| TX-CC1000-2B | 1.0mm×2 | 2.2/4.4mm±0.1 | ≤200 | PE | 1250 | -55~70 |
