Optical fiber cable is a transparent tube can’t light up by itself, need light source used together,can show various colors.If you need a light source, welcome to choose and buy in my store.
1.5 Mm PMMA Plastic For Lighting
NewDescription
Description:
1. Bare fiber optic light
2. Diameter: 0.25mm, 0.5mm, 0.75mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm, 2.5mm, 3.0mm
3. Attenuation: Within 200dB/km(except 0.25mm attenuation within 350dB/km)
4. Material: PMMA
Specification:
| Product name | PMMA side glow fiber 1.5mm |
| Brand | TXPOF |
| Model | TX-FL1500 |
| Outer diameter | 1.5mm |
| Spool Length | 700m/Spool |
| Cladding material | None |
| Typical Attenuation | <0.25dB/m |
| Minimum Bend Radius | 4.5mm |
| Weight | 0.4kgs |
| Certification | ROHS approved |
Feature:
1. Colorful, flexible transmission
2. Cold light source, low attenuation, high lighting effective, longer shelf life
3. No ultraviolet ray, safe, Separate light from electric
4. Small optical loss, high brightness, full chromaticity
Application
1. Optical fiber lamps, optical fiber adornment engineering
2. Historic and jewelry preservation, dangerous area and mine workings special places lighting
3. Indoor, outdoor and other various environment
Certificate
As we take quality as our priority. In the process of development, we passed “ISO9001”, “REACH”, “SGS” professional certifications.Also,we are the only “UL” certified company in POF field of China.
